• Production Varieties: Corrugated paper, high-strength corrugated paper, liner paper, kraft paper

• Net Paper Width: 4200mm

• Forming Width: 4500mm

• Design Speed: 400mm/min

• Working Speed: 350mm/min

• Rail Pitch: 5400mm

• Transmission Mode: Frequency conversion divisional transmission

• Air-Cushion Headbox: Produced in 2013 by Xi’an Weiya, with a lip width of 4500mm

• Wire Systems: Bottom net length 21 meters; second net length 8 meters

• Dehydration Elements: Stainless steel box with ceramic panels; frame covered with stainless steel

• Core Rollers:

• • Breast roll: 65046505400mm

• • Guide roller: 35046505400mm

• • Screen drive roller: 650465005400mm

• • Double suction vacuum roll: 90047005450mm

• Auxiliary Equipment: 3.5-square-meter and 2-square-meter Shuntong front screens; flushing pump

• Roll Configuration: Two large roll diameters

• • Artificial stone roller: 135046505450mm

• • Blind hole rubber roller: 135046505450mm

• Frame: Outsourced with stainless steel

• Guide Roller: Rubber-coated guide roller (340465005450mm)

2.3 Drying Section

• Drying Cylinders: 38 pieces of 180046505450mm drying cylinders (5 sets, 5kg pressure, manufactured in 2012 with complete certificates)

• Guide Roller: Stainless steel guide roller (32046505450mm)

• Tightener: Cast Iron Rack Rail Type Blanket Tightener

• Auxiliary Equipment:

• • 1 horizontal roll machine (6 roll rolls)

• • 1 set of sizing machine (with spare rolls, 1000/4650/5450mm)

• • 1 set of down thread rewinder (speed: 1300m)

• 2 turbo blowers (made by Zhenxing)

• ABB frequency converter

• Shuangyuan scanning frame

• Frequency conversion screw air compressor

• Thin oil lubrication station
