Basic Parameters

• Design Speed: 550m/min
• Operating Speed: 420m/min
• Applicable Products: Kraft paper & similar grades (60g~300g)

1. Fourdrinier Section

• Full stainless steel air-cushion headbox (manufactured by Xi’an Weiyang)
• Stainless steel-clad frame
• Ceramic-faced dewatering elements
• Stainless steel vacuum boxes
• Φ800mm vacuum couch roll
• Complete vacuum system and flow delivery system equipped with transmission unit

2. Press Section

• 2 sets of large-diameter press rolls (Φ1320mm), including complete accessories and transmission unit
• 1 set of vacuum press rolls (Φ850~900mm), including complete accessories, transmission unit and vacuum system

3. Dryer Section

• 42 sets of enclosed gearbox cylinder groups (Φ1800×4250mm)
• Arrangement: 30 groups + size press + 12 groups

4. Other Key Components

• 1 set of Zhejiang Zhengda electronic scanner (including radioactive source)
• Full set of horizontal pneumatic reel
• 1 set of down-winding high-speed slitter rewinder (including matching motor and control system)
• Complete set of electrical appliances and control system for the whole machine

Machine Status
