Product Varieties: Linerboard paper, high-wafer strong corrugated paper
-
Basis Weight: 80–180g/m²
-
Trimmed Width of Net Paper: 3800mm
-
Working Speed: 380–400m/min
-
Capacity: 200t/d
-
Place of Origin: Hutai Chang’e Machinery Co., Ltd.
① Wire Section: The bottom mesh is 21m, the upper wire is 7m; the air-cushion headbox slurry mouth is 4100㎜ (Xi’an Weiyang); the dehydration element is a stainless steel ceramic panel; the vacuum roller diameter is 900mm (effective suction area 4100㎜); the drive screen roller is ∅800 mm.
② Pressing Section: Two large rollers with a pressing diameter of 1320×4150×4800㎜; 4 pieces of blind rubber hole rollers.
③ Drying Section: 30 pieces of cylinder drying group (20+10); “Chang’e dryer cylinder 5kg pressure”; ∅1800×4150×4800mm; drying cylinder direct connection +felt roller transmission mode.
④ One gluing machine is ∅900×4150×4800㎜.
⑤ The spare roller has a new large diameter, along with a vacuum lying roller and a guide roller.
⑥ One water scanner.
⑦ One horizontal pneumatic paper winding machine; vacuum system: Tianjin turbine fan + water ring vacuum pump.
-
Transmission Mode: Variable frequency drive.
