Machine Basic Info
  • Model:  1880 Tissue Paper Machine
  • Purpose: Tissue paper production
Core Technical Parameters
  • Working Width: 2400 mm
  • Dryer Cylinder Diameter: 2500 mm
  • Center Distance: 2800 mm
  • Production Capacity: 4–5 tons
Rewinder Specifications
  • Working Width: 2400 mm
  • Diameter: 900 mm
Key Component Specifications
1. Felt Guide Roll
  • Specifications: Ø194 × 2500 × 2800 mm
  • Surface: Stainless steel with rubber coating
2. Grooved Press Roll
  • Specifications: Ø550 × 2400 × 2800 mm
3. Wire Section (Breast Roll)
  • Specifications: Ø1500 × 2350 × 2800 mm
  • Side Panels: Stainless steel
4. Vacuum Couch Roll
  • Specifications: Ø530 × 2400 × 2800 mm
5. Wire Box
  • Type: Standard plastic wire box
Motor & Gearbox Systems
  • Main Drive Motor & Gearbox (Integrated Unit): 45 kW
  • Rewinder Motor & Gearbox (Integrated Unit): 5.5 kW
Equipment Features
  • Complete set of equipment
