For Sale: Used 3500 Tissue Paper Machine
Type: Vacuum Mould Tissue Paper Machine
Capacity: 20-30 TPD
Status: Dismantled
Machine Specifications
  1. Design speed: 600 m/min; Working speed: 530 m/min
  2. Configuration: 1 horizontal winder
  3. Main structure:
    1. Diameter: 3000 mm; Working surface: 3850 mm
    2. 1 drying cylinder (Yanke cylinder)
    3. Small gear box for power transmission
    4. 160kw motor
  4. Roller: 750 mm diameter (blind hole roller)
  5. Vacuum system:
    1. 950 mm diameter vacuum circular wire
    2. 1×160kw Roots blower (including motor)
    3. 1×17 vacuum pump (including motor)
  6. Breathing hood (equipped with 1 blower and 1 induced draft fan)
  7. Screening device: 1 set of 2㎡ Pre-Net Screen (manufactured by Shandong Jiefeng Machinery Manufacturing Co., Ltd)
  8. Auxiliary parts: Motors, cabinets and frequency converters are fully equipped
