For Sale: Used 4400/400 Two-Wire Multi-Cylinder Paper Machine (Left-Hand Machine)
Manufacturer: Jiaozuo Chongyi Light Industrial Machinery Co., Ltd.
Year of Manufacture: 2012
Applicable Paper Grade: High-strength corrugated paper, T paper (80-200g/m²), kraft paper, liner paper
Design Speed: 400 m/min
Working Speed: 380 m/min
Production Capacity: 200-260 TPD
1. Double Fourdrinier Wire Section
- Wire table length: 21+7m
- Headbox: 2 sets of air cushion type (manufactured by Hangzhou Meichen Paper Industry Technology Co., Ltd.), lip width 4800 mm
- Dehydration element: Composed of stainless steel box + ceramic panel; frame covered with stainless steel
- Key rollers (specifications: diameter x length):
- Breast roller: φ700×5100 mm
- Vacuum couch roll: φ900×5100 mm
- Drive roller: φ800×5100 mm
- Steering roller: φ700×5100 mm
- Composite roll: φ800×5100 mm
- Guide roller: φ387×5100 mm
2. Press Section (K Press + Large Roll Diameter Configuration)
- K press components (specifications: diameter x length):
- K press 1: Vacuum suction roller (φ600×4900 mm)
- K press vacuum roller: φ1000×4900 mm
- K press upper roller: φ1050×4900 mm
- K press lower roller: φ950×4900 mm
- Large roll diameter component: Press roll (φ1350×4900 mm)
- Press frame: Covered with stainless steel
3. Drying Section
- Arrangement form: 1+2/2+8+10+S+12
- Drying cylinders: 32 pieces (specification: φ1800×4960 mm, with cylinder head rope groove); 5-piece set, working pressure 0.5Mpa, 4 of which are chrome-plated
- Paper guide cylinder: 1 piece (specification: φ1500×4960 mm, with cylinder head paper guide rope groove); working pressure 0.3Mpa, chrome-plated
- UNO cylinders: 2 pieces (specification: φ1500×4960 mm, with cylinder head car rope groove)
- Transmission mode: Closed gear box transmission, lubricated by thin oil
- Operation side frame: Covered with stainless steel
4. Other Core Components
- Hood: Simple enclosed hood
- Sizing machine: Inclined sizing machine (sizing roller specification: φ1000/φ1010×4800 mm), equipped with glue system
- Roll bank: Simple roll bank paper machine; paper roll specification: φ520×4800 mm, 8 pieces in total
- Winder: Underfeed winder (manufactured by Boshan)
5. Auxiliary Systems & Equipment
- Control system: Full set of ABB control system
- Scanning frame: 2 sets (manufactured by Shuangyuan Company)
- Turbine fans: 2 pieces (manufactured by Hangzhou Zhenxing)
- Additional equipment: Front flow pressure screen, flushing pump, thin oil station, hydraulic station, double-rope threading system
