1. 3600 Type Double Fourdrinier Paper Machine

Main Parameters

• Design: Double fourdrinier
• Finishing & Testing Equipment: Underfeed winder, Pneumatic reeler, Moisture tester
• Two-roll calender (roll diameter: 700 mm)
• Drying Cylinders: 30 pcs, diameter 1500 mm, face length 4000 mm
• Middle size press
• Press Section: 1 press roll (diameter 1300 mm) + 1 vacuum press roll (Total: two press sections)
• Production Speed: 300 m/min

2. 3200 Type Triple Fourdrinier Paper Machine

Main Parameters

• Design: Triple fourdrinier
• Finishing & Testing Equipment: Underfeed winder, Pneumatic reeler, Moisture tester
• Two-roll calender
• Drying Cylinders: 34 pcs, diameter 1500 mm, face length 3700 mm
• Middle size press
• Press Section: 1 press roll (diameter 1250 mm) + 1 press roll (diameter 1150 mm) + 1 vacuum press roll (Total: three press sections)
• Production Speed: 250 m/min
