2800/300m Two-Wire Multi-Dryers Paper Machine

• Manufacturer of Main Machine: Xuchang Zhongya
• Wire Specifications:
  • Bottom wire length: 17.5 meters
  • Top wire length: 7 meters
• Headbox Supplier: Xi’an Weiya
• Frame & Dewatering Components:
  • Rotating beam of the frame: Covered with stainless steel
  • Dewatering element box: Made of stainless steel (with ceramic panels)
• Vacuum Roller: Diameter 800x3300x3800 mm
• Vacuum Press Rollers:
  • One vacuum press roller diameter: 800 mm
  • Another vacuum press roller diameter: 750 mm
  • Additional roller diameter: 1300 mm
• Drying Cylinder:
  • Diameter: 1500x3200x3800 mm
  • Configuration: 36-cylinder group
  • Transmission: Sealed gear box
• Oblique Size Press: Roller diameter 850 mm
• Additional Key Components:
  • Two-roller calender
  • Pope reel
  • Frame rewinding system
